XPS
Modern thermal insulation materials made of extruded polystyrene foam improve energy efficiency and extend the life of facilities in all sectors of construction
THERMAL
INSULATION
Benefits of PNP XPS
Constantly low thermal conductivity of PNP ensures persistently high heat-shield performance of a structure throughout the entire service life of a facility, regardless of operation conditions.
Thermal conductivity
PNP is produced on modern equipment using innovative CFC-free technologies.
Environment-friendly
PNP due to its closed cellular structure does not absorb water and retains all declared properties throughout the entire service life of construction, even in case of direct long-term contact with water.
Moisture resistance
PNP does not emit harmful substances such as phenols, isocyanates into the air and does not contain hexabromocyclododecane (HBCD).
Safety
PNP does not represent a media for the bacteria or mold growth, and other harmful microorganisms, ensuring the safety and durability of the facility as a whole.
Biostability
Operational lifetime of material is more than 50 years.
Durability
Products
Extruded polystyrene PNP is an effective thermal insulation for all building industry areas. Due to its high performance, the extruded polystyrene is widely used in the construction of residential, public, industrial and private buildings, agricultural and public buildings. Also, the material is required for the insulation of pipelines and as the basis for covering roads, railways, runways.
PNP 150 MG
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 20-150
Surface type : milled and grooved
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 20-150
Surface type : milled and grooved
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
PNP 200 MG
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 20-150
Surface type : milled and grooved
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 20-150
Surface type : milled and grooved
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
PNP 200
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 20-150
Surface type : smooth
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 20-150
Surface type : smooth
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
PNP 300 MG
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 20-150
Surface type : milled and grooved
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 20-150
Surface type : milled and grooved
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
PNP 150
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 20-150
Surface type : smooth
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 20-150
Surface type : smooth
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
PNP 300
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 20-150
Surface type : smooth
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 20-150
Surface type : smooth
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
PNP 500
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 40-100
Surface type : smooth
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 40-100
Surface type : smooth
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
PNP 700
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 40-100
Surface type : smooth
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
Length, mm : 1185
Width, mm : 585
Nominal thickness, mm : 40-100
Surface type : smooth
Edge type : straight edge (С)/
L-shaped edge (T-15)
SM EN 13164:2014+ A1:2016
(EN 13164:2012+ A1:2015)
A special type of boards designed for use under plaster or tile finish. The boards have a milled rough surface with grooves, which improves the adhesion of plaster and adhesive compounds to the material surface.
PNP 700
Extremely strength type of boards recommended for use in structures where special requirements are imposed on the structure in terms of loads, including for road construction.
PNP 500
High strength type of boards recommended for use in structures where strong requirements are imposed on the structure in terms of loads, including for road construction.
PNP 200
Universal type of boards with a smooth surface, recommended for thermal insulation of plinths, walls (except for plaster systems), floors, roofs, as a filler for expansion joints.
PNP 150 MG
A special type of boards designed for use under plaster or tile finish. The boards have a milled rough surface with grooves, which improves the adhesion of plaster and adhesive compounds to the material surface.
PNP 150
Universal type of на boards with a smooth surface, recommended for thermal insulation of plinths, walls (except for plaster systems), roofs, balconies and loggias.
PNP 300
Universal type of boards with a smooth surface, recommended for thermal insulation of loadable structures: foundations, floors, stylobates, accessible roofs, paving systems and landscaping improvement.
PNP 300 MG
A special type of boards designed for use under plaster or tile finish. The boards have a milled rough surface with grooves, which improves the adhesion of plaster and adhesive compounds to the material surface.
All PNP thermal insulation products were successfully tested and have all needed set of permits.
Reasons to choose
PNP solutions provide high class
of fire safety
of fire safety
PNP products are specified by high thermal uniformity. It allows to substantially minimize heat loss through boundary contour and provide an opportunity to increase the level of energy efficiency of the building.
PNP solutions increase the level of energy efficiency of buildings
Сonsistently high thermal efficiency of PNP thermal insulation allows to get bigger area for exploitation by overall decrease of thickness of boundary contour. Аll of it increases the profitability of the project.
PNP solutions increase the profitability of the project
Essential qualities for thermal insulation are moisture resistance and biostability especially in underground structures and areas: PNP products absolutely comply with these requirements. It allows to optimize the temperature and humidity in basements and parking spaces.
PNP solutions provides complience with the sanitary and hygienic norms
Applications
Thermal insulation of foundations, buried structures
Thermal insulation of underground parkings
Thermal insulation of floors
Thermal insulation of systems of paving and improvement of territory
Thermal insulation of underground parkings
Thermal insulation of floors
Thermal insulation of systems of paving and improvement of territory
Thermal insulation of roofs
Filling of expansion joints and thermal-
insulating inserts
Thermal insulation of walls
Thermal insulation of highway structures
Filling of expansion joints and thermal-
insulating inserts
Thermal insulation of walls
Thermal insulation of highway structures
Professional PNP solutions are applied in all construction systems and sectors
Private
construction
construction
Sport venue
construction
construction
Residential
construction
construction
Transport
construction
construction
Public building
construction
construction
Agro-industrial
construction
construction
Pipeline and
utility systems
utility systems
Industrial
construction
construction
Low-rise housing
construction
construction
The company's products are widely applied in industrial, civil construction, as well as for the construction of private houses and apartment renovation. We purpose to raise the culture of construction and make our world a better place: creating energy-efficient, comfortable and durable objects upon architectural projects of any level of complexity.
About company
ORANGE TOWER S.R.L. is a manufacturer of modern energy efficient thermal-insulation materials made of extruded polystyrene foam under brand PNP. We create innovative solutions to improve energy efficiency and extend operation life of facilities in all sectors of the construction industry.
The company is founded in 2020. The head office of the company is located in the Ungheni city, Republic of Moldova. Consumers and experts in the construction industry have already appreciated products of the company in regards to their unique technical characteristics. Demand for PNP materials is growing rapidly. Due to its proven effectiveness PNP XPS is supplied to more than 15 countries.
